Specification
Audio and Video
IP Camera Input 16 Channel
Display
Interface 1 RJ45 10M/100M self-adaptive Ethernet Interface
Rear panel: 2 x USB2.0
Live view display: 1/4/6/8/9/16
Resolution
VGA Output
1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
HDMI Output
3840×2160/30Hz, 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz
Decoding Capacity
Format: Ultra 265/H.265/H.264
Multi-Screen Display
Synchronous Playback : 16-ch
Recording
Compression
Audio Compression: G.711A, G.711U
Resolution 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF
Video Detection And Alarm
Video Detection
Face detection, Intrusion detection, Cross line detection, Audio detection, Defocus detection, Scene change detection, Auto tracking, Object Left Behind, Object Removed, Face search, Behavior search, People counting
Playback And Backup
Sync Playback
16 channel
Network
Interface
1 RJ45
Ethernet Port
10M/100M, self-adaptive ethernet interface
Network Function
Incoming Bandwidth: 64Mbps
Outgoing Bandwidth: 48Mbps
Maximum User Access
Remote Users: 128
Storage
Internal HDD
1 SATA interface
HDD Mode Up to 8TB
Auxiliary Interface
USB Rear panel: 2 x USB2.0
Power
Power Supply 12V DC
Power Consumption Power Consumption: ≤5 W (without HDD)
Component Environment
Operational Conditions -10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing)
Construction
Dimensions 260mm × 240mm × 46mm (10.2″×9.4″×1.8 “)
Net Weight ≤0.98kg (2.16 lb)
Warranty
Manufacturing Warranty 1 year Warranty
