Mechanical
Dimensions
Ø415 x 303 mm (Ø16.34 x 11.93″)
Weight
Without Mount: 1.3 kg (2.87 lb)
With Mount: 1.8 kg (3.97 lb)
Enclosure Characteristics
Aluminum / UV Stabilized Polycarbonate
Hardware
Processor
Quad-Core ARM Cortex A7
Memory 256 MB DDR3
Networking Interface
10/100/1000 Mbps Ethernet RJ45
RF Connections Internal
Max. Power Consumption 11W
Power Method
Passive PoE (Pairs 4, 5+; 7, 😎
Power Supply
24VDC, 0.5A Gigabit PoE Adapter
Supported Voltage Range 22 to 26VDC
ESD/EMP Protection
Air/Contact: ± 24kV
Operating Temperature -40 to 60° C (-40 to 140° F)
Operating Humidity 5 – 95% Noncondensing
Certifications FCC, IC, CE
LEDs Power
Flashing White: Bootup in Progress
White: System Ready, Ubiquiti® Internet Service Provider (UISP™) Not Configured, Not Connected
Flashing Blue: System Ready, UISP Configured, but Cannot Connect
Blue: System Ready, UISP Configured and Connected
Ethernet
Flashing Blue: Ethernet Traffic Detected
5G Blue: Active Connection
60G Blue: Active Connection
Software OS airOS®
Operating Modes PtP
Ubiquiti Specific Features
Integrated 60 GHz and 5 GHz Radios, Discovery Protocol
Security
WPA2 AES Only
Dashboard Yes
Wireless Settings Yes
Network Settings Yes
System Yes
Services
UISP, Ping Watchdog, Web Server, SSH Server, NTP Client, System Log, Device Discovery
Tools
Antenna Alignment Tool, Discovery Utility, Traceroute, Speed Test
Minimum Software Requirements
Any Modern Web Browser
